The Simucube 3 Pro takes the benchmark 25 Nm of the Simucube 2 Pro into Simucube's third generation. A direct-drive optimised SPM motor, a 23-bit encoder and next-generation telemetry processing give maximum torque and detail, in a unified ecosystem with a contactless quick release.
-
25 Nm max torque: full-strength direct drive for any car, any sim
-
Direct drive optimised SPM motor: smooth, low-ripple force feedback
-
23-bit absolute encoder: over 8,000,000 steps per revolution
- 360 W continuous / 450 W peak power supply
-
Full-metal casing: 135 x 135 x 303 mm with the quick release, 11 kg
-
Two options: with or without the Simucube Link Hub
A PC wheelbase for all major racing sims. You'll need the Link Quick Release for Simucube 3 to fit your wheel.
Technical specifications
- Maximum Torque: 25 Nm
- Motor: Direct Drive Optimised Surface Permanent Magnet (SPM)
- Angle Sensor: 23-bit absolute encoder (8,000,000+ steps)
- Power Supply: 360 W continuous / 450 W peak
- Dimensions: 135 x 135 x 303 mm (with Link Quick Release)
- Weight: 11.0 kg, industrial full-metal casing
In the box
- 1x Simucube 3 Pro wheelbase
- 1x Power adapter
- 1x RJ45 cable
- 1x AC power cord
- 1x Quick Start Guide
- 1x Control box
- Simucube Link Hub ("Including Simucube Link" option only)
Before you order
- The Link Quick Release for Simucube 3 is not included: add it to connect your wheel.
- The Simucube Link Hub is only included with the "Including Simucube Link" option.
- Mount it on a rigid cockpit, or on a flat wheel deck with the Simucube Mounting bracket.
- PC only: not compatible with consoles.
- Ordered on demand from the manufacturer for you: allow 2 to 2½ weeks for delivery.
